HE515CM-GR
$447.05
The HE515CM-GR is a rugged micro reflex optic designed for rifles and carbines where durability, precision, and compact size matter.
Its 7075-T6 aluminum housing and green Multi-Reticle System deliver adaptable aiming in a lightweight platform, while Shake Awake and a side-loading battery tray ensure reliable, long-lasting performance.
→ Multi-Reticle System (MRS)
Selectable 2 MOA dot, 65 MOA circle, or circle-dot combination for versatile rifle performance.
→ High-Visibility Green LED
540nm Green Super LED delivers a crisp aiming point with up to 50,000 hours of battery life.
→ 7075-T6 Aluminum Housing
Lightweight, high-strength aluminum construction built for demanding environments.
→ Shake Awake Technology
Motion-activated system powers the optic on instantly while preserving battery life when idle.
→ Side-Loading Battery Tray
CR2032 battery replacement without removing the optic from the firearm.
→ Quick Detach Lower 1/3 Mount
QD mount with 1.63 inch dot height for fast installation and lower 1/3 co-witness alignment.
→ Sealed Environmental Protection
IP68-rated waterproof and dustproof construction built for extreme conditions.
Reticle Options
Features
- Green Multi-Reticle System
Selectable green reticle with 2 MOA dot, 65 MOA circle, or combined circle dot for precision aiming or rapid target acquisition. - Enhanced Green Super LED
540nm green emitter delivers strong contrast and excellent visibility across lighting conditions with up to 50,000 hours of battery life. - 7075-T6 Aluminum Housing
Precision machined aluminum construction provides exceptional strength and durability while maintaining a lightweight micro optic footprint. - Shake Awake Technology
Motion activated illumination powers the optic instantly when movement is detected and powers down during inactivity to conserve battery life. - Side Loading CR2032 Battery Tray
Tool-less battery tray allows quick battery replacement without removing the optic from the firearm. - Lower 1/3 Co-Witness QD Mount
Integrated quick detach mount positions the optic at a 1.63 inch height for optimal lower 1/3 co-witness with AR platform iron sights. - Removable and Rotating Lens Caps
Protective lens caps keep the glass shielded from dust and debris while allowing quick deployment when needed. - IP68 Waterproof Protection
Fully sealed optic housing provides advanced protection from water, dust, and harsh environmental conditions. - Multi-Coated Optical System
Advanced lens coatings enhance light transmission and reduce glare for a clearer sight picture. - Compact Micro Reflex Design
Lightweight and streamlined optic body designed for rifles, carbines, and PCC platforms requiring a durable micro sight.
FUNCTIONS
Selectable Reticle
Yes
Solar Power
No
Shake Awake Technology
Yes
Auto Off
Yes
Memory
Yes
Manual Brightness
Yes
Automatic Brightness
No
Lockout Mode
Yes
OPTICAL DATA
Light Source
LED
Wavelength
540nm
Reticle
2 MOA Dot & 65 MOA Circle
Magnification
1x
Parallax
No
Unlimited Eye Relief
Yes
Multi-Coatings
Yes
ELECTRONIC DATA
Battery
CR2032
Battery Life (Setting 6)
50,000 Hours
Brightness Setting
8 Daylight & 4 NV
Removable Battery
Yes
Battery Location
Side Tray
MECHANICAL DATA
Housing Material
6061 T6 Aluminum
Surface Finish
MAO
Housing Color
Black
Adjustment Per Click
0.5 MOA
W&E Travel Range
±50 MOA
Storage Terperature
-40°C~70°C
Working Temperature
-30°C~60°C
Submersion
IPX8
Vibration
1000G
PHYSICAL DATA
Window Size (in)
0.91" x 1.26"
Dimension (in) Body
3.35" x 1.63" x 1.7"
Body (oz) Weight
9.17 oz
Fitment
Direct Mount
Picatinny Rail
In The Box
HE515CM-GR
Len Cloth
Multi-Tool
Manual
Warranty Card
